The Really Useful Guide to Specifying,
Buying, and Commissioning Steam Jet Ejector Systems
Jerzy Olejniczak
First edition, 2001.
21 pages; English.
Format: Adobe PDF. |
This 21 page, 9000+ word e-book has been written by a retired project engineer
with many years experience of vacuum projects. The aim of the booklet is simple
- to transfer that experience to you, and is packed full of essential advice and
tips.
- Chapter 1 - Defining your project and Vacuum Process
Requirements
Looks at the different type of vacuum producer and some
key points to be borne in mind at this stage.
|
- Chapter 2 - Process Requirements
Looks at the conditions for a suitable steam jet ejector
system. Covers utilities, steam requirements, cooling water, condensate
treatment and discharge from the ejectors.
|
- Chapter 3 - Selection of an Arrangement of Ejectors
Talks about plant quality, vacuum standards and how to
identify an initial ejector arrangement. Discusses use of direct condensers
and water ring pumps.
|
- Chapter 4 - Evaluation, Optimisation and Ordering
Discusses how to select and test the performance of a
proposed ejector arrangement. Working with the manufacturer and placing of
the order.
|
- Chapter 5 - Supply of the Vacuum Producers and its
Components
Discusses delivery of the ordered solution from supplier, and
issues that can arise.
|
- Chapter 6 - Build and Assemble the Vacuum Producer
Brief discussion as to how this should be done.
|
- Chapter 7 - Vacuum Tightness Testing
Looks at the tests to be run and the traps to be aware of.
|
- Chapter 8 - Testing of the Vacuum Producer
Looks at the tests to be run to prove the specifications have
been met and the traps to be aware of.
|
- Chapter 9 - Operation Training
Preparing for production.
|
- Chapter 10 - Production
Issues to be aware of as the plant finally goes into
production.
|
| |
How to read the e-book?
The guide is supplied only as an e-book in Adobe PDF format.
You require a copy of Adobe Acrobat reader, which is available free from Adobe.
Just click on the link at the foot of this page to download the reader.
Pricing
The guide is priced at 19 British pounds (GBP).
Approximate conversions to US$ and € are:
| GBP19 |
= |
US$27.50 |
| GBP19 |
= |
€31 |
The exact amount charged to your credit card will
depend upon the exchange rate at the time you place your order. You can perform
a currency conversion using a link on the order page.
How do I get The Guide?
There are just four simple steps
-
Either use out on-line credit card ordering facility
(click here) or our
buy by mail facility (click here) to pay for a copy. We will email you an
unlocking password when payment has been received.
-
Download the PDF from the link below
-
Download and install Adobe Acrobat reader if you don't already
have it installed.
-
Wait for our email with the unlocking password.
That's it.. you are then ready to run Adobe Acrobat and read The
Really Useful Guide to Specifying, Buying and Commissioning Steam Jet Ejector
Systems.
Downloads
Click
to download The Guide.
The Really Useful Guide to Specifying, Buying and Commissioning Steam Jet
Ejector Systems
